With turbocharger
DESCRIPTION FUSE RATING PROTECTED COMPONENT
1 FAN 70A Cooling fan
2
― ― ―
3 BTN 40A For protection of various circuits
4 HEAD 40A Headlights
5 F/PUMP 30A Fuel pump
6
― ― ―
7 ABS 1 30A ABS, DSC
8 ABS 2 20A ABS, DSC
9 ENGINE 30A For protection of various circuits
10 INJECTOR 30A Fuel injector
11 IG KEY1 30A Ignition switch
12 STATER 20A Starter clutch
13 IG KEY2 30A Ignition switch
14
― ― ―
15 HEATER 40A Blower motor
16
― ― ―
17 DEFOG 40A Rear window deforester
18 AUDIO 30A
Audio system
(BOSE Sound System-equipped model)
19 ABS IG 10A ABS
20 FOG 15A Front fog lights
21 HORN 15A Horn
22 DRL 10A DRL
í
23 H/CLEAN ― ―
24 ETC 10A Elec. throttle valve
25
― ― ―
26 A/C MAG 10A Air conditioner
27
― ― ―
28
― ― ―
29 P.OUTLET 15A Power outlet
30 ENG +B 10A PCM
31 ROOM 15A Interior lights
32
― ― ―
33 ENG BAR 3 10A O
2
sensors
34
― ― ―
35 ENG BAR 1 15A For protection of various circuits
36 ENG BAR 2 10A PCM, Fuel pump
