Owner maintenance – Mazda 2007 3 4-DOOR User Manual
Page 322
Black plate (321,1)
2. Pull the center of each plastic retainer
and remove the retainers and partially
open the trunk side trim.
Removal
Installation
3. Turn the socket and bulb assembly
counterclockwise and remove it.
4. Disconnect the bulb from the socket.
5. Install the new bulb in the reverse order
of removal.
NOTE
To replace the bulb, contact an
Authorized Mazda Dealer.
Rear turn signal lights (5 Door)
1. Remove the cover.
Left side
Right side
2. Turn the socket and bulb assembly
counterclockwise and remove it.
3. Disconnect the bulb from the socket.
Maintenance and Care
Owner Maintenance
8-47
Mazda3_8V66-EA-06F_Edition2 Page321
Friday, May 26 2006 10:56 AM
Form No.8V66-EA-06F
