Replacing a fog light bulb
í
1. Turn the screw counterclockwise and
remove it and partially peel back the
mudguard.
2. Disconnect the electrical connector
from the bulb by pressing the tab on
the connector with your finger and
pulling the connector downward.
3. Turn the socket and bulb assembly to
remove it. Carefully remove the bulb
from its socket in the reflector by
gently pulling it straight backward out
of the socket.
4. Install the new bulb in the reverse order
of removal.
NOTE
l To replace the bulb, contact an
Authorized Mazda Dealer.
l If the halogen bulb is accidentally
touched, it should be cleaned with
rubbing alcohol before being used.
l Use the protective cover and carton
for the replacement bulb to dispose
of the old bulb promptly and out of
the reach of children.
Front turn signal lights/Side-marker
lights
Due to the complexity and difficulty of
the procedure, the bulbs should be
replaced by an Authorized Mazda Dealer.
Side turn signal lights
1. Slide the unit as shown in the figure to
remove it.
2. Detach the electrical connector from
the unit by pulling it to the rear.
3. Install the new side turn signal unit in
the reverse order of removal.
8-44
Maintenance and Care
í
Some models.
