DCA-800SSK (STD) — OPERATION AND PARTS MANUAL — REV. #4 (06/03/10) — PAGE 47
14. The engine oil pressure gauge (Figure 47) will indicate
the oil pressure (kg/ cm 2 ) of the engine. Under normal
operating conditions the oil pressure is approximately
Figure 47. Oil Pressure Gauge
Figure 49. Engine Tachometer Gauge
16. The tachometer gauge (Figure 49) will indicate the
speed of the engine when the generator is operating.
Under normal operating conditions this speed is
approximately 1800 RPM’s.
15. The coolant temperature gauge (Figure 48) will indicate
the coolant temperature. Under normal operating
conditions the coolant temperature should be between
165 and 215 degrees Fahrenheit (
Green Zone).
Figure 48. Coolant Temperature Gauge
WATER TEMP
0
4
8
kg/cm2
ENGINE OIL PRESSURE
Figure 50. Main, Aux. and GFCI
Circuit Breakers (ON)
17. Place the main, GFCI, and aux. circuit breakers in the
“ON” position (Figure 50).
18. Observe the generator's ammeter (Figure 51) and verify
it reads the anticipated amount of current with respect
to the load. The ammeter will only display a current
reading if a load is in use.
19. The generator will run until manually stopped or an
abnormal condition occurs.
Figure 51. Ammeter (Load)
DCA-800SSK — GENERATOR START-UP PROCEDURE (MANUAL)
