PAGE 36 — DCA-800SSK (STD) — OPERATION AND PARTS MANUAL — REV. #4 (06/03/10)
Generator Output Voltages
A wide range of voltages are available to supply voltage for
many different applications. Voltages are selected by apply-
ing jumpers (6) to the
voltage change-over board (Figure 15).
To obtain some of the voltages as listed in Table 7 (see
below) will require a fine adjustment using the
voltage regu-
lator (VR) control knob located on the control panel.
Voltage Change-Over Board
The
voltage change-over board (Figure 15) is located on
the control box, behind the generator control panel. This
board has been provided for ease of voltage selection.
Figure 15. Voltage Change-Over Board
240V Configuration
DCA-800SSK — GENERATOR OUTPUTS
Generator Amperage
Tables 8 and 9 describe the generator’s current output capa-
bility for both 1Ø-phase and 3Ø phase applications.
