25
At a glance
Instrument cluster
Item Page
1 Coolant temperature gauge 141
2 Fuel gauge with fuel tank
reserve warning lamp
341
3 L Left turn signal
indicator lamp
51
K Right turn signal
indicator lamp
51
4 Speedometer with:
v Electronic Stability
Program (ESP)
warning lamp
343
l Distance warning
lamp
Vehicles without Distronic*:
Distance warning lamp with-
out function. It illuminates
when the ignition is on. It
should go out when the en-
gine is running.
342
5 Tachometer 142
Item Page
6 Right display with:
< Seat belt telltale 343
A High beam headlamp
indicator lamp
50
- Antilock Brake
System (ABS)
indicator lamp
338
7 J Reset button 140
8 Display with:
ț Gear selector lever
position 174
ț Program mode 174
ț Digital clock
(see COMAND operating
instructions)
9 Multifunction display
with:
ț Trip odometer 141
ț Main odometer 141
Item Page
a Outside temperature
indicator
142
b Left display with:
1 Supplemental
restraint system
indicator lamp
345
; Brake warning lamp,
USA only
339
3 Brake warning lamp,
Canada only
? Engine malfunction
indicator lamp,
USA only
340
± Engine malfunction
indicator lamp,
Canada only
H Tire inflation pres-
sure warning lamp
307
c Knob for instrument cluster
illumination
140
