4.4.2.3 F52 – User Spacecraft Mean Elements
MsgID Chars. Format Description
F52 95 User spacecraft mean elements
1 x
3 xxx Message Id (=F52)
4 xxxx GPS week of epoch
11 xxxxxxx.xxx GPS seconds of week [s] of epoch
11 xxxxxx.xxxx SGP4 mean semi-major axis a [km]
11 xx.xxxxxxxx SGP4 mean eccentricity e
9 xxxxx.xxxx SGP4 mean inclination i [deg]
10 xxxxx.xxxx SGP4 mean right ascension of ascending node
Ω
[deg]
10 xxxxx.xxxx SGP4 mean argument of perigee
ω
[deg]
10 xxxxx.xxxx SGP4 mean mean anomaly M [deg]
12 xxx.xxxxxxxx SGP4 ballistic coefficient B
2 xx Checksum
1 x
Example:
F521079 475200.000 6933.6698 0.00108870 97.6045 143.0131 277.5609 82.
4397 -0.003070225C
