4.4.1.11 F45– Relative Navigation Data (WGS-84 System)
MsgID Chars. Format Description
F45 104 Relative navigation data (WGS-84 system)
1 x
3 xxx Message Id (=F45)
4 xxxx GPS week
12 xxxxxx.xxxxx GPS seconds of week [s] (of navigation solution)
2 xx GPS-UTC [s]
12 sxxxxxxxx.xx ∆r
x
(x position difference remote –local) [m]
12 sxxxxxxxx.xx ∆r
y
(y position difference) [m]
12 sxxxxxxxx.xx ∆r
z
(z position difference) [m]
12 sxxxxx.xxxxx ∆v
x
(x velocity difference remote–local) [m]
12 sxxxxx.xxxxx ∆v
y
(y velocity difference) [m]
12 sxxxxx.xxxxx ∆v
z
(z velocity difference) [m]
1 x Navigation status (0=no-Nav,2=3D-Nav)
2 xx Number of tracked satellites (remote receiver)
4 xx.x PDOP (remote receiver)
2 xx Checksum
1 x
Example:
F451139172978.0000013 +653.26 +2342.55 -11667.94 +0.26231
+13.04631 +2.648422 6 2.66A
4.4.1.12 F46 – Relative Navigation Data (RTN Frame)
MsgID Chars. Format Description
F46 104 Relative navigation data (RTN frame)
1 x
3 xxx Message Id (=F46)
4 xxxx GPS week
12 xxxxxx.xxxxx GPS seconds of week [s] (of navigation solution)
2 xx GPS-UTC [s]
12 sxxxxxxxx.xx ∆r
R
(radial position difference; local-remote) [m]
12 sxxxxxxxx.xx ∆r
T
(along-track position difference) [m]
12 sxxxxxxxx.xx ∆r
N
(cross-track position difference) [m]
12 sxxxxx.xxxxx ∆v
R
(radial velocity difference; local-remote) [m]
12 sxxxxx.xxxxx ∆v
T
(along-track velocity difference) [m]
12 sxxxxx.xxxxx ∆v
N
(cross-track velocity difference) [m]
1 x Navigation status (0=no-Nav,2=3D-Nav)
2 xx Number of tracked satellites (remote receiver)
4 xx.x PDOP (remote receiver)
2 xx Checksum
1 x
Example:
F461139172978.0000013 -12.20 -11918.68 -0.00 -0.01829 +0
.01417 -0.003602 6 2.673
