4.3.1.2
DR – Data Rate
The DR command provides the means for an individual configuration of receiver output mes-
sages. Sentences can be deactivated completely, polled once or issued at selected intervals.
CmdID Chars. Format
Description
DR
11
Data Rate
1 x
2 xx
Command Id (=DR)
2 xx
Message number
3 x(xx)
Output interval (-1..127)
2 xx
Checksum
1 x
Notes:
•
The output interval specifies the time between consecutive messages of the re-
quested frame number in units of the time interval between navigation solutions (i.e.
1 s for 1 Hz version, 0.5 s for 2 Hz version)
•
A value of “-1” for the output interval is used to deactivate a given message
•
An output interval of “0” requests a one-time output (polling) of the given message
•
Negative message numbers control the output of NMEA type message (-1=GPGGA,
etc.)
Examples:
Issue the F40 navigation message at each update
Deactivate the F43 channel status message
Poll the current configuration and status parameters (F48 msg.)
4.3.1.3
SM – Sentence Mode
The sentence mode command can be used to increase the field width of various Winmon
sentences (F00, F03, F04) to accommodate increased altitude, velocity and Doppler values
as encountered in typical space applications.
CmdID Chars. Format
Description
SM
7
Sentence Mode
1 x
2 xx
Command Id (=SM)
1 x
Sentence Mode (0=Winmon,1=Winmon-X)
2 xx
Checksum
1 x
Example:
Select standard WinMon format for F00, F03, and F04
Select extended WinMon format
