69D0023 45
FIREBOX COMPONENTS
ILLUSTRATED PARTS LISTS
Item Description Qty CDVR33 CDVT33 CDVR36 CDVT36
Standard Features
1 Junction Box Assembly 1 26D2128K 26D2128K 26D2128K 26D2128K
2 Black Louver 6 54D0246 54D0246 26D0695 26D0695
3 Glass Frame Assembly 1 69D0238 69D0238 69D0028 69D0028
Factory Installed Service Parts
2 Brass Louver 6 54D0249K 54D0249K 26D0701K 26D0701K
4 Thermostat Sensor (Blower) 1 26D2870 26D2870 26D2870 26D2870
5 Cottage Clay Firebrick Rear 1 69D0221 26D7069 69D0040 —
5 Cottage Clay Firebrick Rear 1 — — 69D0041
5 Tavern Brown Firebrick Rear 1 69D0222 54D0284 69D0044 —
5 Tavern Brown Firebrick Rear 1 — — — 69D0045
6 Cottage Clay Firebrick Right/Left 2 26D7068 26D7068 69D0042 69D0042
6 Tavern Brown Firebrick Right/Left 2 54D0285 54D0285 69D0046 69D0046
7 Blower Motor 1 26D0748 26D0748 26D0748 26D0748
Accessories/Field Installed Options
2 Brass Louver 1 L30BR L30BR L32BR L32BR
2 Pewter Louver 1 L30PW L30PW L32PW L32PW
9 Curved Design - Brass Trim 1 BRTK30C BRTK30C BRTK32C BRTK32C
9 Curved Design – Pewter Trim 1 PWTK30C PWTK30C PWTK32C PWTK32C
10 T-stat Blower with Speed Control 1 BLOT BLOT BLOT BLOT
