Securing fireplace to floor or framing – Monessen Hearth Direct Vent Gas Fireplace CDVR36 User Manual
Page 12
12
69D0023
Drywall Support Tabs
(Do Not Use for Framing
or Header)
The fireplace must be secured to the floor and/or to framing studs as shown in Figure 8. Use two (2) wood screws or masonry/
concrete screws to secure fireplace to the floor. Use four (4) screws to attach fireplace to framing. The side nailing flanges
are
1
/
2
" or
5
/
8
" to accommodate different wall thickness.
SECURING FIREPLACE TO FLOOR OR FRAMING
Figure 8 - Securing Fireplace to Floor and Framing Studs (CDVT36 shown)
Screws
Framing
Framing
Nailing
Flange
Nailing
Flange
Screws
Screws
Nailing
Flange
Nailing
Flange
