Multiquip pOrtable generatOr (HOnda gX340 gasOline engine) gaC6HZ - Manual (Page 10)

page 10 — gaC-6HZ 60 HZ geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)
speCifiCatiOns (generatOr)
Table 1. specifications (generator)
aC generator
Model GAC6HZ
Type Brushless Revolving Field Type
Excitation Solid State, Statically Excited System
Speed 3,600 RPM
Cooling System Self-Ventilation
Fuel Capacity 5 gallons (19 liters)
60 Hz aC power source
Continuous Power Output 5.0 kW
Max Power Output 6.0 kW
Rated Voltage 120/240V
Current Max/Continuous (120V) 50.0/41.6 amps
Current Max/Continuous (240V) 25.0/20.8 amps
Phase Single Phase (3 wire)
Frequency 60 Hz
Power Factor 1
dimensions
(l x W x H)
30.70 x 20.27 X 18.89 in.
(780 X 515 X 480 mm)
dry Net Weight 216 lbs. (98 kg.)
NOTICE
In keeping with Multiquip's policy of constantly
improving its products, the specifications quoted herein
are subject to change without prior notice.
