MAINTENANCE
12
F-050204L
LUBRICATION
How To Lubricate
The Jackshaft Assembly
A grease fitting is provided to lubricate the
jackshaft assembly. Use a grease gun with au-
tomotive type grease to lubricate the jackshaft
assembly as shown in Figure 9.
Figure 9
Grease Fitting
How To Change Engine Oil
Change the engine oil when the engine is
warm. For the proper oil capacity, see the en-
gine manufacturer’s instructions.
1. Disconnect spark plug wire from the spark
plug.
2. Remove the oil drain plug as shown in
Figure 10.
3. Drain all the engine oil into a flat pan.
4. Install the oil drain plug. Make sure the
oil drain plug is tight.
5. Remove the dipstick.
6. Fill the engine crankcase. DO NOT
OVERFILL. For proper oil capacity, see
the engine manufacturer’s instructions.
7. Connect the spark plug wire to the spark
plug.
Figure 10
Oil Drain Plug
