C-40 Country-Specific Information
Countr
y
-S
pecific
Infor
m
a
ti
on
3261 Modem
Table C-18 describes DIAL LINE connector pinouts for RJ jack types. X indicates
the signal is active.
Table C-19 describes PHONE connector pinouts for RJ jack types. X indicates the
signal is active.
Table C-18.
DIAL LINE Connector Pinouts for Jack Operation
PHONE Connector
Pin No.
PHONE Jack
Function
TELCO Jack Selection
RJ4MB
RJ45S
RJ16C
RJ11C
1
MB
X
Not Used
Not Used
Not Used
2
MB1
X
Not Used
Not Used
Not Used
3
MI
X
X
X
Not Used
4
Ring
X
X
X
X
5
Tip
X
X
X
X
6
MIC
X
X
X
Not Used
7
PR
X
X
Not Used
Not Used
8
PC
X
X
Not Used
Not Used
Table C-19.
PHONE Connector Pinouts for Jack Operation
PHONE Connector
Pin No.
PHONE Jack
Function
TELCO Jack Selection
RJ4MB
RJ45S
RJ16C
RJ11C
1
N/C
N/C
N/C
N/C
N/C
2
N/C
N/C
N/C
N/C
N/C
3
MI
X
X
X
Not Used
4
Ring
X
X
X
X
5
Tip
X
X
X
X
6
MIC
X
X
X
Not Used
7
N/C
N/C
N/C
N/C
N/C
8
N/C
N/C
N/C
N/C
N/C
N/C = Not Connected
