Chapter 3: Software Installation
Multi-Tech Systems, Inc. 29
Actions:
• Select Outbound Phone Book
o
Select Add Entry
o
Accept Any Number may be selected to allow unmatched destinations an alternative
o
Enter the number necessary to get out from the PBX system followed by the calling code of the
destination in the Destination Pattern field
o
Enter the PBX access digit (same number as needed to get out of the PBX system) in the
Remove Prefix field
o
Any digits that need to be added should be put in the Add Prefix field
o
Enter the IP address of the call destination (add a Description if you like)
o
Select a Protocol type (–SS models use SIP only, -FX models do not support H.323)
ƒ For H.323:
• Enter Gateway settings
ƒ For SIP:
• Select Transport Protocol, Proxy and URL if needed
ƒ For SPP:
• Enter Registrar settings if needed
o
The Advanced Button will allow an Alternate IP Address to be entered for outbound traffic
• Select Inbound Phone Book
o
Select Add Entry
o
Accept Any Number for inbound traffic does not work when external routing devices are used
o
Enter any access digits followed by the local calling code in the Remove Prefix field
o
Enter any digits needed to access an outside line in the Add Prefix field
o
Select Hunting in the Channel Number field to have the VOIP use the next available channel
o
Add a description if you like
o
Call Forward may be set up (details available in Chapter 5)
o
Select Registration Option
• Repeat the Phone Book steps for any additional entries needed
Save & Reboot
Any time that you change settings on the VOIP unit, you must choose the Save & Reboot option; otherwise all
changes made will be lost when the MultiVOIP is reset or shutdown.
