Chapter 3: Software Installation
Multi-Tech Systems, Inc. 24
Actions:
• Select Channel
o
Select Interface Type: FXS, FXO, E&M or DID (FXS/FXO only for –SS and –FX series)
o
Regeneration
ƒ Choose how signal is regenerated; as Pulse or DTMF
o
Inter Digit Timer
ƒ Time the MultiVOIP waits between digits
o
Message Waiting Indication is for E&M only
ƒ Choose Light or None
o
Inter Digit Regeneration Timer
ƒ Length of time between sent DTMF digits
• Flash Hook Options
o
Generation (used in conjunction with FXO/E&M)
o
Detection Range (used in conjunction with FXS/E&M)
• Caller ID
o
Bellcore is the only option available
o
CallerID Manipulation is available if needed
o
CID Manipulation is not available in the –SS models
• Pass Through (opens an audio path through the MultiVOIP)
• FXS Options
o
Set Ring Count (the number of rings allowed before call abandoned; default is 8)
o
Use Current Loss (MultiVOIP interrupts current to disconnect)
o
Generate Current Reversal (activates Answer/Disconnect Supervision to FXO)
• FXO Options
o
Ring Count (set number of rings before MultiVOIP answers)
o
No Response Timer (set time to attempt call before abandoning)
o
Supervision Button (for call answering and disconnection settings)
ƒ Answer Fields:
• Current Reversal (use current reversal to answer)
• Answer Delay
• Answer Delay Timer (in seconds)
• Tone Detection (allow tone sequence to disconnect)
• Available Tones
• Answer Tones (shows current selection from Available Tones)
ƒ Disconnect Fields
• Current Reversal (use current reversal to disconnect)
• Current Loss (loss of current will trigger disconnect)
• Current Loss Timer (time after current loss to disconnect; in milliseconds)
• Silence Detection Enable (use silence detection to disconnect)
• Silence Detection Type (one-way or two-way)
• Silence Timer (time of silence needed to trigger disconnect; in seconds)
• DTMF Tone (use tones to disconnect)
• Disconnect Tone Sequence (select tone pairs to use for disconnecting)
• Tone Detection (disconnect from termination of tone)
• Available Tones
• Disconnect Tones (shows current selection from Available Tones)
• E&M Options (not supported by –SS and –FX series)
o
Type
o
Mode (2-wire or 4-wire)
o
Signal (Dial Tone or Wink)
o
Wink Timer (range is 100 to 350 milliseconds; default is 250)
o
No Response Timer (time, in seconds, after which an FXO call would be disconnected)
o
Disconnect on Call Progress Tone (allows disconnection when PBX issues call progress tone)
o
Pass Through Enable (creates an open audio patch; not for use with Wink signaling)
• DID Options (not supported by –SS and –FX series)
o
Start Modes (Immediate, Wink or Delay Dial)
o
Wink Timer (in milliseconds)
