LED Function Summary
Power DSL Internet
Unlit No power No signal Not connected
Solid Green Power on DSL line synched with
the DSLAM Connected to the Internet
Flashing Green N/A Activity on the DSL cable Transmitting or receiving
data on the WAN port
Solid Red System malfunction N/A N/A
Flashing Red Updating embedded soft-
ware N/A N/A
Ethernet 1, 2, 3, 4 WPS Wireless
Unlit No signal No wireless signal No wireless signal
Solid Green Synched with Ethernet
card WPS exchange with
client is successful N/A
Flashing Green Activity on the Ethernet
cable N/A Activity on the wireless
LAN
Solid Red N/A N/A N/A
Flashing Red N/A N/A N/A
