10

58D6002

ON

OFF

L

2

L

1

W

H

GENERAL INSTALLATION INFORMATION

The following formula can be used to determine the maximum heater rating per the definition of unconfined space:

BTU/Hr = (L

1

+ L

) Ft x (W) Ft x (H) Ft
0

Consider two connecting rooms with an open area between, with the following dimensions:

L

1

= 1

1

/

Ft., L

= 1 Ft., W = 1 Ft., H = 8 Ft.

BTU/Hr = (1

1

/

+ 1) x (1) x (8)

0

If there were a door between the two rooms the calculation would be based only on the room with the heater.

BTU/Hr = (1

1

/

) x (1) x (8)

0

Figure 4 - Example of a Large Room with 1/2 Wall Divider

Counter

Cast Iron Stove

x 1000

x 1000 = 800 BTU/Hr

x 1000 = 960 BTU/Hr

W

ARNING

If the area in which the heater may be operated is smaller than that defined as an

unconfined space or if the building is of unusually tight construction, provide adequate

combustion and ventilation air by one of the methods described in the National Fuel

Gas Code, ANSI Z223.1, NFPA54, Section 5.3 or applicable local codes.
