Makita HP2031 - Manual (Page 4)

4 Model HP2030 *
4 Model HP2031
3. Change on Switch and Handle Set
Item No. Description Type 1 Type 2
53 Switch 651935-4 651986-7 (651987-5)
59 Handle Set 182724-1
Higher Higher Height Lower Rib Height
Above parts are completely interchangeable as a set.
When installing the Type 2 Switch on the current Left Handle, be sure to cut the rib by 7.0 to 8.0mm.
Item No. Description Type 1 Type 2
25 Cam Hsg. Com. 159793-7(No Longer Available) 151764-0
35 Flat Washer 16 253707-9 - - - - -
Serial No. N/A N/A
Above parts are completely interchangeable as a set.
When replacing Cam Housing Com. Type 1 with Cam Hsg. Com Type 2 always remove the Item 35 on
the Fan side of the Armature.
2. Change on Cam Housing Com.
