Makita HP2031 User Manual
Page 2
2 Model HP2030
*
2 Model HP2031
Item
Part
No.
No.
No.
Used
Description
Item
Part
No.
No.
No.
Used
Description
1
251425-3
1
(-) Flat Head Screw M6x22(Type 1)
251460-1
1
(-) Flat Head Screw M6x22(Type 2)
251464-3
1
(-) Flat Head Screw M6x22 W/Glue
(Type 3)
3
*
1
Spindle
4
921919-9
1
Hex Bolt M8x110
5
415485-1
1
Grip Base
6
415614-6
1
Gear Hsg.
7
211012-0
1
Ball Bearing 606ZZ
8
226818-3
1
Gear Com. 8-19-25
9
211012-0
1
Ball Bearing 606ZZ
10
213314-0
1
Oil Seal 19
11
344177-4
1
Cup Washer 26
12
233091-8
1
Compression Spring 16
13
211206-7
1
Ball Bearing 6202LLB
14
962153-2
1
Retaining Ring R-35
15
961055-9
1
Retaining Ring S-15
16
226289-4
1
Spur Gear 27-38
17
223104-3
1
Cam A
18
*
1
Steel Ball
19
213759-2
1
O Ring 72
20
232053-3
1
Leaf Spring
21
415619-6
1
Change Lever A
22
344178-2
1
Lock Plate
23
213162-7
1
O Ring 14
24
322787-7
1
Change Pin 8
25
*
1
Cam Hsg Com.
26
256251-5
1
Pin 4 (Old 256226-4)
27
415621-9
1
Rack12
28
344179-0
1
Change Plate
29
344178-2
1
Lock Plate
30
232143-2
1
Leaf Spring
31
415620-1
1
Change Lever B
32
213162-7
1
O Ring 14
33
152521-9
1
Grip 36 Com. (Old 152489-9)
(Includes Hex Nut M8 - 931402-8)
34
415615-4
1
Cam Hsg Cover
35
253707-9
1
Flat Washer 16
*
36
210005-4
1
Ball Bearing 608DDW
37
241850-6
1
Fan 60
38
517101-2
1
Armature Assy
(Includes Items 36, 37, 39 & 40)
39
681614-0
1
Insulation Washer
40
211026-9
1
Ball Bearing 627LLB
41
253707-9
1
Flat Washer 16
42
415618-8
1
Baffle Plate
43
633410-2
1
Field (Old 633295-6)
44
415601-5
1
Motor Hsg.
45
643923-5
2
Brush Holder
46
191927-6
2
Carbon Brush CB-407 (2pcs/Set)
47
858233-9
1
Name Plate F/HP2030
858234-7
1
Name Plate F/HP2031
48
415622-7
2
Brush Holder Plate
49
266007-8
4
Tapping Screw Bind PT3x10
50
421505-1
1
Cushion Rubber
51
265995-6
5
Tapping Screw 4x18
52
182724-1
1
Handle Set (Old 415616-2)
53
*
1
Switch
54
410102-8
1
Key Holder (For 1/2" & 5/8" Chuck Key)
55
265995-6
2
Tapping Screw 4x18
56
687063-9
1
Strain Relief
57
682549-8
1
Cord Guard 8-85
58
664013-1
1
Cord With Plug 2P-18-2.5M
59
182724-1
1
Handle Set (Old 415617-0)
*
60
819063-3
1
Makita Label
61
266060-4
2
Tapping Screw Flange PT4x65
62
266038-7
4
Tapping Screw Flange PT5x70
