3 Model HP2030 *
3 Model HP2031
SERVICE CHANGES
1. Change on Spindle, Steel Ball and Pin 4.
Item No. Description Type 1 Type 2
3 Spindle 322786-9 323854-1
18 Steel Ball 216018-3 (Size 5) 216001-0 (Size 3.5)
63 Pin 4 - - - - - 256251-5 (Added)
Serial No. ~ 38634 E 38635E ~
Above parts are completely interchangeable as a set.
Item Part No.
No. No. Used Description
Item Part No.
No. No. Used Description
63 256251-5 1 Pin 4 (Added) *
100 534024-9 1 Lead Assy (Purple)
(Receptacle & Lead Wire)
101 534023-1 1 Lead Assy (Orange)
(Receptacle & Lead Wire)
102 654126-6 2 Tab
103 654069-2 2 Receptacle
Accessories
A01 192552-6 1 1/2" Drill Chuck & Chuck Key Set
(HP2030)
192664-5 1 1/2" Keyless Chuck (HP2031)
(Old 192521-7)
A02 415486-9 1 Depth Gauge
A03 763440-0 1 Chuck Key S13 (HP2030)
A04 824485-4 1 Plastic Carrying Case
A05 - - - - 1 Hammer Bit
(See Catalogue for Details)
A06 765009-6 1 Blow-Out Bulb 64
A07 192985-5 1 Grip Assy (Includes Items 4, 5, & 33)
(Old 152489-0A)
