Woodworking

102

KP312

Precision Engineered for an Even Cut Every Time

Planing width 12-1/4"

Planing depth 1/8"

No load speed 12,000 RPM

AMPS (115V) 15.0

Overall length 21-3/4"

Net weight 40.6 lbs.

Shipping weight 50.6 lbs.

• Powerful 15 AMP motor with 12,000 RPM
• Poly “V” belt designed with grooves efficiently transfers power from the

motor to the blades

• Large ejection chute for high rate of chip discharge
• Front roller for easy moving over rough materials
• Externally accessible brushes for easier serviceability
• Large, conveniently located depth setting knob for easy adjustment

MODEL KP312 INCLUDES: Socket wrench (782209-3),

Triangular rule (762001-3), Blade set (B-02870)

Specifications:

12-1/4" Planer

98202

Precision Sharpening of Planer Blades and More

Wheel size 7-7/8"

No load speed 560 RPM

AMPS (115V) 1.1

Overall length 15-3/8"

Net weight 24.3 lbs.

Shipping weight 26.9 lbs.

• Large 7-7/8" aluminum-oxide wheel for efficient sharpening
• Quiet motor delivers 560 RPM for a fine finish
• Sharpens blades up to 15-3/4" long
• Water feed for cooling blades
• Less weight for easy transporting

MODEL 98202 INCLUDES: Grinding wheel (A-24614), Blade holder

(123061-4A), Wrench (341391-3), Rule assembly (122209-5)

Specifications:

Blade Sharpener

3901

Rack-and-Pinion Vertical Fence Adjustment

Blade diameter 4"

Max. cutting depth 25/32"

No load speed 10,000 RPM

AMPS (120V) 5.6

Overall length 12-3/32"

Net weight 6.6 lbs.

Shipping weight 11.4 lbs.

• Easy rack-and-pinion vertical adjustment of angle guide
• Shaft lock for easy blade changes; easy to operate cam locks
• Non-marring rubber strip insert prevents slipping of material
• Cast aluminum pivot fence with positive stops at 0º, 45º and 90º

MODEL 3901 INCLUDES: Carbide tipped blade (A-94982), Angle guide

(122475-4), Dust bag (122474-6), Lock nut wrench (782401-1), Set plate
(415579-2), Inner flange (224280-6), Lock nut (224505-8),
Tool case (824437-5)

Specifications:

Plate Joiner

7104L

Ideal for Timber Framing or Log Home Building

Capacities: Max. hole width (longitudinal) 5-1/8"

Max. hole width (transverse) 7-1/4"
Max. hole depth 6-1/8"

No load speed 3,200 RPM

Chain Speed 1,000 ft./min.

AMPS (120V) 10.5

Overall length 15-1/4"

Net weight 38.1 lbs.

Shipping weight 44.0 lbs.

• Razor sharp chain for clean, accurate cutting
• Extremely portable at only 38.1 lbs.
• 10.5 AMP motor (3,200 RPM) to quickly notch or cut holes in thick

wood stock

• Cuts lap joints up to 5-1/8"
• Large adjustable vise and knob for versatility

MODEL 7104L INCLUDES: 23/32" (18.25 mm) Cutter chain (A-16570),

Sharpening holder (123028-2), Wrench (781204-0), Oil supply
(182229-1)100cc

Specifications:

Chain Mortiser

UB1101

Variable Speed

Delivers a Maximum Air Velocity of 114 MPH

Max. air volume 99 cfm

Max. air velocity 114 MPH

No load speed 0 - 16,000 RPM

AMPS (115V) 5.5

Overall length 18-7/8"

Net weight 4.1 lbs.

Shipping weight 6.6 lbs.

• Two tools in one; converts to a vacuum for reaching confined areas
• Variable speed control dial (0 - 16,000 RPM)
• Maximum air volume of 99 cfm
• Ergonomic handle design for comfortable use in horizontal and

downward applications

• Large trigger with conveniently located lock-on button
• Compact with less weight

MODEL UB1101 INCLUDES: Long Nozzle (134182-7), Dust bag (122321-1)

Specifications:

Blower

HG1100

Compact and Lightweight for Easy Handling

Air temperature 250º-1,100ºF

Air volume 8 and 14 cfm

AMPS (120V) 12.5

Watts (AC only) 1,500

Overall length 10"

Net weight 1.3 lbs.

Shipping weight 1.5 lbs.

• Strips paint and varnish, thaws frozen metal pipes, loosens tile and

putty, remelts adhesives and more

• Variable temperature control (250º - 1,100ºF) for a wide variety of

applications

• 2-speed blower setting (8 or 14 cfm)
• Thermocouple control maintains precise temperature
• Ceramic core protects the heating element for longer tool life

MODEL HG1100 INCLUDES: Tool only

Specifications:

Heat Gun
