The HDD Drives User's Guide
4.4 Removing The Hard Disk Drives
Below is the procedure on how to remove the hard disk drives.
•
Make sure the system is properly
shutdown.
• Flip the system upside down as
shown.
• Remove the battery pack as shown in
Chapter 2.
• Remove the two screws as shown by
#1.
• Remove the two HDD drives as
shown by #2.
•
Remove the four screws as shown by
#1.
• Before removing the HDD module,
first remove the HDD door as shown
by #2.
HDD Drive
To insert the HDD drive, reverse the steps above.
Page 4-4
