The HDD Drives User's Guide
4.2 For RAID Users
Your notebook supports RAID 0 and RAID 1 technology. In order to take advantage of
this capability, you need to perform the below one-time procedure before installing
Windows™ Vista™ operating system:
• Install two SATA HDDs into the two HDD sockets.
• Insert “Windows™ Vista™ SP1 OS” into the ODD drive.
• Boot up system. Press F2 during boot up to enter BIOS Setup.
• In BIOS Setup, set the SATA Mode Selection in Advanced menu to “RAID Enable”.
• In BIOS Setup, press F10 to save change and then exit BIOS Setup.
• When system display “Intel(R) Matrix Storage Manager” screen, press
simultaneously to enter Configuration Utility.
• Follow instruction to complete the RAID setup.
• Boot up and install Windows™ Vista™ from the ODD drive.
Page 4-2
