Troubleshooting Procedures
!
WARNING
To avoid risk of electrical shock, personal injury or death; disconnect power to washer before servicing, unless
testing requires power.
June 2006 11 16026882
©2006 Maytag Services RPL 16026127
Display Diagnostic Codes
The diagnostic code display can be toggled
‘ON’ and ‘OFF’ from Service Mode by pressing the
Rinse & Spin
key and rotating the Rotary Cycle
Selector knob. The display will show a “d”.
Rotating the Rotary Cycle Selector knob in either
direction will cycle through the list of codes one code at
a time with no wrap. Once an initial direction is selected
by the user (either Clockwise or Counterclockwise),
subsequent movements of the knob in the same
direction will show older codes. If the user changes
direction and turns the Rotary Cycle Selector knob in
the opposite direction, the more recent code will be
displayed. If rotation is continued to the limits of the list,
the display will remain at the top or the end of the list. A
pair of dashes “- -” will be displayed at the end of the list
of codes, when the control reaches the top, it will again
show “d”.
A code generated during the current cycle will be
displayed with the Spin Speed LED turned ‘ON’. If no
cycle is currently running, a code generated during the
previous cycle will be displayed with the Spin Speed
LED turned ‘ON’.
Access Other Features
While a diagnostic code is displayed, if the Rotary
Cycle Selector
knob is pressed and held, the machine
will display the number of cycles since the diagnostic
code occurred.
Clear Diagnostic Codes
To clear the diagnostic codes list, press the Delay and
Chime
keys for 3 seconds while viewing the list.
Diagnostic Codes
Diag.
Code
Description Trigger Action to be
taken
1 No Drain
The water level
fails to drop
below the Low
Water level reset
within 15
minutes, before
a spin begins.
Displays "nd".
See Will Not Drain
“Troubleshooting
Procedures”.
2
The door
fails to
unlock
Door failed to
unlock after 3
attempts
Displays "LO". See
Will Not Unlock
“Troubleshooting
Procedures”.
3 No Fill
Continuous fill of
12 minutes.
Total fill of 14
minutes.
Displays "nF".
See No Water Fill
“Troubleshooting
Procedures”.
Diag.
Code
Description Trigger Action to be
taken
4
The door/lid
fails to lock
Door failed to
lock after 3
attempts
Displays "FL".See
Will Not Lock
“Troubleshooting
Procedures”.
5-7 Not Used
8
Water level
sensor fault.
Input signal from
water level
sensor is out of
range, Washer
will beep and
pause the wash
cycle.
Displays "LE". See
No Water Fill
“Troubleshooting
Procedures”.
9 Not Used
10
Unbalance
or cabinet
hit detected
during final
spin, which
prevented
the spinner
from
exceeding
400 rpm
Never exceeded
400 rpm due to
an unbalanced
load.
Will display “dc”
See Wet Clothes
"Troubleshooting
Procedures".
E
Water
sensor level
fault.
Water level in
the machine is
believed to be
above the
overflow level.
When this
condition is
detected, the
machine will
automatically
begin pumping
water out until it
falls below the
overflow level.
First check to see
that water valve is
not stuck. If water
valve is OK, check
water level sensor.
11
Will not
remember
machine
settings
Difficulty in
reading memory
See Clear
Diagnostic
Codes.
Disconnect and
reconnect the
washer power cord
at power supply
outlet.
If condition still
exists, replace
machine control
board.
12-14 Not Used
