8
REMOTE CONTROL
1. POWER Button - Press to turn the TV/VCR on. Press
again to turn the TV/VCR off.
2. Direct Channel Selection Buttons (0-9) - Allows
direct access to any channel.
3. MENU Button - Press to display the On-Screen menu
function.
4. VOL + / – and B / A (cursor) buttons
VOL + / – : Press the + button to increase, or the – button
to decrease the volume level.
B / A (cursor) : Select an item or adjust the setting in
the menu.
5. INPUT SELECT Button - Switches the program for
viewing between the VCR and external input sources.
6. REW (Rewind) Button - In the Stop mode, this button
rapidly winds the tape backwards. In the Play mode,
this button activates reverse search.
7. INDEX + / – buttons - Search for the INDEX mark of a
tape.
8. REC/OTR Button - Press once to start normal
recording. Additional presses activate One-touch
Timer Recording.
9. AUTO TRACKING Button - Allows automatic adjust-
ment of tracking to minimize picture noise during
playback.
10. SPEED Button - Sets the tape speed for recording.
11. EJECT Button - Press to eject the tape.
12. TV MONI. Button - Used to temporarily view a TV chan-
nel selected on the VCR while in the playback mode.
13. TV/CAP/TEXT Button - Switches between Caption, Text
and TV modes for Closed-Captioned programs.
14. PROGRAM Button - Press to confirm the programmed
timer recording and ON/OFF timer.
15. CANCEL Button - Used to clear the selected program
and to move the cursor backward.
16. MUTE Button - Press to turn off the sound. Press
again to turn the sound back on.
DESCRIPTION OF CONTROLS
17. F.FWD (Fast Forward) Button - In the Stop mode, this
button rapidly winds the tape forward. In the Play
mode, this button activates forward search.
18. PAUSE/STILL Button - During recording, this button
temporarily stops the tape. During playback, it stops
the tape and displays a still image on the TV screen.
19. SKIP SEARCH Button - Press in the playback mode
to search forward in 30 second increments to a
maximum of 3 minutes.
20. COUNTER RESET Button - Used to reset the counter
to “00:00:00”.
21. CALL Button - Displays the present time/day of the
week, channel, counter, speed selection (and VCR
mode if VCR is playing) on the TV screen.
22. CH (CHANNEL) M / ? M / ? M / ? M / ? M / ? and ▲ / ▼ (cursor) buttons
CH (CHANNEL) M / ? M / ? M / ? M / ? M / ? : Press the M M M M M button to change
to a higher numbered channel set into memory. Press
the
? ? ? ? ? button to change to a lower numbered channel
set into memory.
▲ / ▼ (cursor) : Selects an item in the menu.
23. PLAY Button - Press to play a prerecorded tape.
24. TIMER REC Button - Used to set the TV/VCR to start
recording at a preset time.
25. TRACKING + / – Buttons - During playback, they are
used to adjust tracking manually.
26. SLEEP Button - Sets the TV to turn off automatically
after up to 120 minutes.
27. QUICK VIEW Button - Switches between the present
channel and the last channel selected.
28. ENTER Button - Press to enter or select information
for on-screen operations.
29. STOP Button - Press once to stop the tape.
30. ZERO RETURN Button - Use to stop the tape when the
counter reaches “00:00:00”.
11 1
2
4
5
3
6
7
8
9
10
12
13
14
15
16
17
18
19
20
21
22
23
24
27
28
25
30
29
26
