Murphy Selectronic DT9800 - Manual (Page 2)

Magnetic Pickup
Murphy offers magnetic pickups
sold separately.
How to Order
When ordering DT9800 series tachome-
ters specify model number and options
(if apply).
Warranty
A two-year limited warranty on materials
and workmanship is given with this
Murphy product. Details are available on
request and are packed with each unit.
Pickup Total Threaded Thread
Models † Length †† Length †† Size
MP3298 3 (76) 3 (76) 5 / 8 -18 UNF
MP7906 3 (76) 3 (76) 3 / 4 - 16 UNF
MP7905 4-1/2 (114) 4-1/2 (114) 3 / 4 - 16 UNF
5-1/16 in.
(129 mm)
4-1/4 in.
(108 mm)
1-9/32 in.
(33 mm)
Dimensions
†Magnetic pickups have lead wire hookups.
††Lengths are in inches and (millimeters).
0 1
2
3
6
9
45 7
8
0 1
2
3
6
9
45 7
8
0 1
2
3
6
9
45 7
8
X 1000 X 100 X 10
0 1 2
3 6
9
45 7 8
0 1 2
3 6
9
45 7 8
0 1 2
3 6
9
45 7 8
1 2 3 4 5 6 7 8 9 10 11 12
OPEN
4 in.
(102 mm) 2 in.
(51 mm)
3-1/2 in.
(89 mm)
2 in.
(51 mm)
3/16 in (5 mm)
diameter, 4 places
3-1/8 in.
(79 mm)
diameter
Mounting Hole
Calibration rocker switches
Back of
DT9800
Series
Overspeed switch (DT9805 and DT9806 only).
Switch shown set at 1850 RPM.
DT9805 - __
Models
DT9803
DT9804
DT9805
DT9806
Options
EX = Explosion-proof
046490 Printed in U.S.A.
®
