Description

The iGUARD™ is one controller for all your
engine-driven generator set applications. It is
designed from the ground up to work with
today’s electronic engines, accepting the J1939
protocol. The iGUARD™ also works with non-
electronic engines.
Designed to meet NFPA-110 and NFPA-99
requirements the iGUARD™ has ample inputs
and outputs.
The new iGUARD™ controller can be used for
all gen-set applications: single-phase or three-
phase, and 12 or 24 V.
Engine speed can be read from a magnetic
pickup,AC generator frequency, or J-1939
CANbus.

Programming Updates in the Field

Because the microprocessor is flash-based, the
controller can be easily re-programmed or
updated using a PC in the field.

Applications

• Packagers and OEM
• Rental Companies
• Prime Power
• Hospitals
• Ground Support Equipment
• Agriculture
• Marine

iGUARD Standard Components

24 - Digital inputs

8 - Analog inputs (one dedicated for
battery)

Inputs for up to three phases and neutral
of AC voltage

Inputs for 3 CT’s for current monitoring

1 - Magnetic pickup input

8 - 20A Form “C” relays

1 - RS232 port

1 - RS485 port

1 - RS232/RS485 port

1 - J1939 port

1 - 64 x 128 pixel full graphic LCD with
backlight

1 - 12 position keypad

Mounts in Several Ways

• Standard set-top
• Alternator mounting
• In existing enclosures

Specifications

Mounting (Cut-out) Dimensions:
7.05 x 5.25 x 2.76 in. (179 x 133 x 70 mm)

Mounting Screws:
4, #6-32 screws and nitrile rubber o-ring are
supplied to meet NEMA4 specs.

Case Material:
Black Polycarbonate, textured finish, UV stabilized.

Connection:
600V rated multi-wire quick connect for DC and
AC connections, suitable for wire harnessing.

Power supply:
Operates from any DC supply for 8-35VDC
continuous. Brownout (5V) ridethrough is 5
seconds and a total blackout (0V) ridethrough of
100 milliseconds.

Vibration/Survivability:
3g, 3 axis, frequency swept 10-1000 Hz.

Operating and Storage Temperature Range:
–40/+185°F (–40/+85°C).

LCD Operating Range:
–4/+176°F (–20/+70°C).

I/O’s:
Expansion relay board available for additional
I/O.
Shipping Dimensions:
10 x 9 x 6 in. (254 x 229 x 152 mm)

Shipping Weights:
2 lb. (910 g.).

Performance Specs

NFPA-110, NFPA-99

SAE Load Dump Test

Approvals

UL/CUL Recognized component as
stand alone controller.

UL/CUL Listed when sold in
conjunction with Murphy
supplied harness.

AL-02058B

Revised 11-05

Catalog Section 75

D

IGITAL

G

ENERATOR

S

ET

C

ONTROLLER

iGUARD

Gen-Set Controller

SAE J1939 Compatible. Reads this

common SAE protocol used on newer
electronic engines.

Universal. This controller fits any

standard gen-set application. Simplify
your life with only one controller to learn
and stock.

Designed to meet NFPA110/NFPA 99

Unmatched Price.

No other controller

has these features at a comparable price.
