Chase installation, 424wbst designer woodburning fireplaces – Monessen Hearth 424WBST User Manual
Page 5
5
424WBST Designer Woodburning Fireplaces
87D1506
Chase Installation
Insulation methods shown are optional
for cold climate, not a requirement for
unit operation.
FP704
Fig. 4 Fireplace and chase parts identification.
FP704
STR (from FP528)
7/28/98
Termination Cap
Storm Collar
Pan Flashing
Draftstop
Finish Wall
Batt Insulation
(cut out around
firestop)
Firestop
Ceiling Level
Outer Dome
Refer to Figures 21
and 26 for clearance
information.
Ledge Brackets
Nailing Flange
Gas Access
(both sides)
Outside Air Cover Plate
Surround
Screen
Grate
Firebox
Outside Air
Control
