17
Model SP-B and SP-C
Deluxe and Standard Ceiling Fan
Model SP-B Dimensions
Model
A
B
C*
D
E
Designer
Grille
Decorative
Grille
Unit
Weight
50, 70 & 80
13
7
⁄
8
(352)
11
1
⁄
2
(292)
7
(179)
6
(152)
1
1
⁄
4
(32) 14
7
⁄
8
x 13
1
⁄
4
(378 x 337)
15
1
⁄
4
(387)
sq.
9
(4)
90, 110, 150,
200
13
7
⁄
8
(352)
11
1
⁄
2
(292)
7
(179)
6
(152)
1
1
⁄
4
(32)
10
(5)
All dimensions are in inches (millimeters) and weight in pounds (kilograms). *Add 1½ in. (38 mm) to C
dimension for incandescent light. Mounting bracket width is 1½ in. (38 mm). For complete dimensional
information, see CAPS submittal drawings.
Model SP-C Dimensions
Model
A
B
C
D
E
F
Decorative
Grille
Unit
Weight
50
7
1
⁄
2
(191)
7
1
⁄
2
(191)
3
5
⁄
8
(92)
3
(76)
1
5
⁄
8
(41)
1/2
(13)
9
1
⁄
4
x 9
(235 x 229)
5
(2)
All dimensions are in inches (millimeters) and weight in pounds (kilograms). For
complete dimensional information, see CAPS submittal drawings.
Model
RPM
Amps*
Watts
CFM / Static Pressure in Inches wg
0
0.1
0.125
0.25
0.375
0.5
0.625
SP-C50
1680
0.80
46
CFM
52
49
49
47
44
38
29
Sones
3.0
3.0
3.0
3.0
3.5
4.0
4.0
A
B
C
D
E
B
C
F
E
D
A
Model
Energy
Star
RPM
Amps*
Watts
CFM / Static Pressure in Inches wg
0
0.1
0.125
0.25
0.375
0.5
0.625
0.75
0.875
1
SP-B50
2, 3, 5
625
0.50
37.8
CFM
67
54
51
40
29
Sones
1.2
1.4
1.4
2.0
3.0
SP-B70
2, 3, 5
675
0.53
45.1
CFM
77
71
68
57
49
39
Sones
1.2
1.4
1.4
2.0
2.5
3.0
SP-B80
2, 3, 5
900
0.60
54.3
CFM
87
80
78
68
61
54
44
30
Sones
2.0
2.0
2.5
2.5
3.0
3.5
4.5
4.5
SP-B90
2, 3, 4, 5
700
0.65
49.7
CFM
101
89
88
75
59
45
30
Sones
1.5
2.0
2.0
2.5
3.0
3.5
4.0
SP-B110
2, 3, 4, 5, 6
950
1.14
80.2
CFM
133
114
110
97
95
94
91
85
72
50
Sones
1.5
1.5
1.5
2.0
2.0
2.0
3.0
3.5
4.0
4.5
SP-B150
2, 3, 4, 5, 6
1050
1.70
128
CFM
160
156
155
154
152
149
147
138
123
92
Sones
2.5
2.5
2.5
3.0
3.5
3.5
4.0
4.5
4.5
5.0
SP-B200
3, 4, 5, 6
1100
2.20
172
CFM
197
195
194
191
187
184
181
166
151
128
Sones
3.5
4.0
4.0
4.5
4.5
5.0
5.0
5.5
5.5
5.5
2 Available with light
3 Available with CRD - Ceiling Radiation Damper
4 Also available with 50 Hz motors
(See page 20 for performance)
5 UL Listed for use above tubs.
6 Available with 277 volt motor.
Performance certified is for model SP exhaust for installation type B: Free inlet, Ducted outlet. Performance ratings include the effects of an inlet grille and backdraft
damper. Speed (rpm) shown is nominal. Performance is based on actual speed of test. The sound ratings shown are loudness values in spherical fan sones at 5 ft (1.5m)
in a spherical free field calculated per Annex B of AMCA 311. Values shown are for installation type B: free inlet spherical fan sone levels.
Performance certified is for model SP exhaust for installation type B: Free inlet, Ducted outlet. Performance ratings include the effects of
an inlet grille and backdraft damper. Speed (rpm) shown is nominal. Performance is based on actual speed of test. The sound ratings shown
are loudness values in spherical fan sones at 5 ft (1.5m) in a spherical free field calculated per Annex B of AMCA 311. Values shown are for
installation type B: free inlet spherical fan sone levels.
*Note: Amp draw is approximate and may vary based on motor manufacturer.
*Note: Amp draw is approximate and may vary based on motor manufacturer.
