G1021X2 15" Planer w/Spiral Cutterhead 13
Table and Base Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
14 PB07M HEX BOLT M8-1.25 X 25 119 P1021X2119 COLUMN
17 PSB02M CAP SCREW M6-1 X 20 120 P1021X2120 CHAIN
19 PK05M KEY 4 X 4 X 10 121 PR05M EXT RETAINING RING 15MM
22 PW04M FLAT WASHER 10MM 122 P1021X2122 IDLER SPROCKET
23 PN08M HEX NUT M10-1.25 123 P1021X2123 SHAFT
27 PW01M FLAT WASHER 8MM 124 P1021X2124 BRACKET
30 PW01M FLAT WASHER 8MM 125 P1021X2125 BASE
46 PSS13M SET SCREW M10-1.5 X 12 126 PB07M HEX BOLT M8-1.25 X 25
47 PSS14M SET SCREW M8-1.25 X 12 127 P6202 BALL BEARING 6202ZZ
105 P1021X2105 EXTENSION TABLE 128 PR21M INT RETAINING RING 35MM
107 P1021X2107 SHAFT 129 P1021X2129 SPROCKET
109 P1021X2109 TABLE ROLLER 130 P1021X2130 COLUMN
109-1 P608-2RS BALL BEARING 608-2RS 131 P1021X2131 SCALE
110 P1021X2110 LOCK HANDLE 1/2-13 132 PS12M PHLP HD SCR M3-.5 X 6
111 P1021X2111 LOCKING ROD 133 PEC12M E-CLIP 12MM
112 P1021X2112 LEAD SCREW 134 P1021X2134 LIFTING SHAFT
113 P1021X2113 MIDDLE TABLE 135 PR01M EXT RETAINING RING 10MM
114 PSS04M SET SCREW M6-1 X 12 136 P1021X2136 GEAR
115 P1021X2115 LOCKING ROD 137 PR22M INT RETAINING RING 38MM
116 P1021X2116 RIVET 2 X 5 138 P1021X2138 BUSHING
117 P1021X2117 SPINDLE NUT 139 P1021X2139 LEAD SCREW (LONG)
118 P1021X2118 ELEV. LEAD SCREW (SHORT) 144 PB118M HEX BOLT M8-1.25 X 45
