G1021X2 15" Planer w/Spiral Cutterhead 10
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P1021X2001 KNOB 5/16-18 57 P1021X2057 SPROCKET
2 P1021X2002 PULLEY COVER 58 PW03M FLAT WASHER 6MM
3 P1021X2003 V-BELT M-59 3L590 59 PB83M HEX BOLT M6-1 X 16
4 P1021X2004 STUD 60 P1021X2060 CHAIN
5 PFB01M FLANGE BOLT M6-1 X 12 63 PR03M EXT RETAINING RING 12MM
6 P1021X2006 BRACKET 64 P1021X2064 CHIP BREAKER ADJUSTMENT ROD
7 PW01M FLAT WASHER 8MM 65 P1021X2065 PIVOT ROD
8 PN02 HEX NUT 5/16-18 66 PN09M HEX NUT M12-1.75
9 PB09M HEX BOLT M8-1.25 X 20 67 PEC05M E-CLIP 15MM
10 PW01M FLAT WASHER 8MM 68 P1021X2068 SPACER
11 P1021X2011 CUTTERHEAD PULLEY 69 P1021X2069 ANTI-KICKBACK FINGER
13 P1021X2013 UPPER COVER 70 P1021X2070 SHAFT
15 PSB01M CAP SCREW M6-1 X 16 71 P1021X2071 INFEED ROLLER
17 PSB02M CAP SCREW M6-1 X 20 72 P1021X2072 SPROCKET
18 P1021X2018 ROLLER STAND 73 PSB26M CAP SCREW M6-1 X 12
19 PK05M KEY 4 X 4 X 10 74 P6204 BALL BEARING 6204ZZ
20 P1021X2020 HANDWHEEL 75 P1021X2075 GEAR
21 P1021X2021 CHIP BREAKER 76 PSB06M CAP SCREW M6-1 X 25
22 PW04M FLAT WASHER 10MM 77 P6201 BALL BEARING 6201ZZ
23 PN08M HEX NUT M10-1.25 78 P1021X2078 GEAR
24 P1021X2024 HANDWHEEL HANDLE M10-1.5 79 P1021X2079 SHAFT
25 P1021X2025 CHIP DEFLECTOR 80 PK06M KEY 5 X 5 X 10
26 PB02M HEX BOLT M6-1 X 12 81 P1021X2081 GEAR CASE COVER
27 PW01M FLAT WASHER 8MM 82 P1021X2082 ALIGNMENT PIN
28 P1021X2028 CHIP BREAKER SPRING 83 P6201 BALL BEARING 6201ZZ
29 P1021X2029 TENSIONING SET SCREW 84 P1021X2084 SHAFT
30 PW01M FLAT WASHER 8MM 85 PK11M KEY 6 X 6 X 40
31 P1021X2031 CHAIN TENSIONER 86 P1021X2086 GEAR
32 P1021X2032 CHAIN TENSIONER SHAFT 87 P1021X2087 KNOB
33 P1021X2033 BRACKET 88 P1021X2088 CHAIN
34 P1021X2034 SHAFT 89 P1021X2089 SPROCKET
35 PRP07M ROLL PIN 6 X 20 90 P1021X2090 OIL PLUG
36 P1021X2036 CHAIN COVER 91 P1021X2091 SEAL
37 PSB05M CAP SCREW M8-1.25 X 50 92 P1021X2092 GEAR BOX COVER
38 PSS11M SET SCREW M6-1 X 16 93 P1021X2093 GASKET
39 P1021X2039 EXTENSION SPRING 94 P1021X2094 DOUBLE GEAR
40 P1021X2040 HANGER 95 P1021X2095 ROLLER SHAFT
41 P6205 BALL BEARING 6205ZZ 96 P1021X2096 DOUBLE GEAR SHAFT
42 PSB04M CAP SCREW M6-1 X 10 97 P1021X2097 COMPRESSION SPRING
43 PK129M KEY 8 X 8 X 36 98 P1021X2098 BALL 6MM
44 P1021X2044 SPIRAL CUTTERHEAD 15" 99 P1021X2099 OIL SEAL
46 PSS13M SET SCREW M10-1.5 X 12 100 P6204 BALL BEARING 6204ZZ
47 PSS14M SET SCREW M8-1.25 X 12 101 PK10M KEY 5 X 5 X 12
48 P1021X2048 COMPRESSION SPRING 102 P1021X2102 SHIFTER
49 P1021X2049 BUSHING BLOCK 103 P1021X2103 SHIFTER SHAFT
50 P1021X2050 BUSHING BLOCK PLATE 104 PORP012 O-RING 11.8 X 2.4 P12
51 PN01M HEX NUT M6-1 108 P608 BALL BEARING 608ZZ
52 P1021X2052 HEAD CASTING 114 PSS04M SET SCREW M6-1 X 12
53 P1021X2053 OUTFEED ROLLER 159 PAW06M HEX WRENCH 6MM
54 P1021X2054 DEPTH LIMITER 160 PAW05M HEX WRENCH 5MM
55 PFH30M FLAT HD SCR M5-.8 X 8 161 PAW04M HEX WRENCH 4MM
56 PK01M KEY 5 X 5 X 22 162 PAW03M HEX WRENCH 3MM
Planer Body Parts List
