GA-8ANXP-D Motherboard - 10 -
English
CPU Š Supports the latest Intel ® Pentium ® 4 LGA775 CPU
Š Supports 800/533MHz FSB
Š L2 cache varies with CPU
Chipset Š Northbridge: Intel ® 925X Express Chipset
Š Southbridge: Intel ® ICH6R
Memory Š 6 DDR II DIMM memory slots (supports up to 4GB memory) (Note 1)
Š Supports dual channel DDR II 600 (Note 2) /533/400 unbrffered DIMM
Š Supports 1.8V DDR II DIMM
Slots Š 1 PCI Express x 16 slot
Š 3 PCI Express x 1 slots
Š 2 PCI slots
IDE Connections Š 1 IDE connection (UDMA 33/ATA 66/ATA 100), allows connection of
2 IDE devices
FDD Connections Š 1 FDD connection, allows connection of 2 FDD devices
Onboard SATA Š 8 Serial ATA ports :
4 ports from ICH6R controller (SATA0_SB, SATA1_SB, SATA2_SB, SATA3_SB);
4 ports from SiI3114 controller (SATA0_SII, SATA1_SII, SATA2_SII, SATA3_SII)
Peripherals Š 1 parallel port supporting Normal/EPP/ECP mode
Š 1 serial port (COMA)
Š 11 USB 2.0/1.1 ports (rear x 4, front x 7 via cable)
Š 3 IEEE1394b ports (requires cable)
Š 1 front audio connector
Š 1 IR connector
Š 1 PS/2 keyboard port
Š 1 PS/2 mouse port
Onboard LAN Š Onboard Marvell 8001 chip (10/100/1000 Mbit) (LAN1)
Š Onboard Broadcom 5751 chip (10/100/1000 Mbit) (LAN2)
Š 2 RJ 45 ports
Onboard Audio Š ALC880 CODEC
Š Supports Jack Sensing function
Š Supports 2 / 4 / 6 / 8 channel audio
Š Supports Line In ; Line Out (Front Speaker Out) ; MIC ; Surround Speaker Out
(Rear Speaker Out) ; Center/Subwoofer Speaker Out ;
Side Speaker Out connection
Š SPDIF In/Out connection
Š CD In connection
1-2 Feature Summary
(Note 1) Due to standard PC architecture, a certain amount of memory is reserved for system usage and
therefore the actual memory size is less than the stated amount.
For example, 4 GB of memory size will instead be shown as 3.xxGB memory during system startup.
(Note 2) To use a DDRII 600 memory module on the motherboard, you must install an 800MHz FSB
processor and overclock in BIOS.
