Know your product
1. Laser light assembly
2. Trigger switch
3. Lock off button
4. Laser light on/off button
5. Motor housing
6. Main handle
7. Front handle
8. Bevel adjustment lever
9. Bevel scale
10. Parallel fence locking knob
11. Parallel fence
12. Base plate
13. Depth locking lever
14. Depth of cut indicator
15. Spindle lock button
16. Disc/Blade
17. Hex key for blade bolt
18. Blade bolt
19a. 90° Blade guide notch
19b. 45° Blade guide notch
20. Upper blade guard
21. Water system port plug
22. Retractable lower blade guard
23. Blade guard lever
24. Water inlet tube
25. Water cock
26. Water distribution tube
27. Parallel fence slots
28. Water tube plug
29. Residual Current Device (RCD)
30. Timber cutting blade
31. Masonry cutting blade
32. Dust extraction adaptor
