h8103 stirling Engine Kit 3
-7-
parts List & Inventory
Ref No. Part ID Part No. Description Quantity
1 HAE0301 PH8103001 ALUMINUM CYLINDER BLANK 40 X 20MM 1
2 HAE0314 PH8103002 BRASS CYLINDER BLANK 8 X 10MM 1
3 HAE0204 PH8103003 BRASS HEXAGON BLANK 5.5 X 36MM 1
4 HAE0302 PH8103004 BRASS PLATE BLANK 85 X 10 X 3MM 1
5 RB2-00 PH8103005 COOLING CYLINDER 40MM 1
6 HAE0215 PH8103006 BRASS CYLINDER BLANK 8 X 20MM 1
7 HAE0216 PH8103007 BRASS ROD BLANK 3 X 19MM 1
9 HAE0309 PH8103009 ALUMINUM PLATE BLANK 130 X 123 X 14MM 1
10 HAE0308 PH8103010 BRASS ROD BLANK 12 X 175MM 1
11 HAE0306 PH8103011 ALUMINUM CYLINDER BLANK 80 X 40MM 1
12 RQ2-00 PH8103012 HEATING CYLINDER 93MM 1
13 P01 PH8103013 WICK HOLDER 1
14 HAE0120 PH8103014 ALUMINUM CYLINDER BLANK 48 X 15MM 1
15 HAE0121 PH8103015 ALUMINUM CYLINDER BLANK 46 X 25MM 1
16 HAE0311 PH8103016 ALUMINUM PLATE BLANK 123 X 123 X 3.75MM 1
19 HAE0209 PH8103019 STEEL ROD BLANK 3 X 87MM 1
20 HAE0310 PH8103020 BRASS CYLINDER BLANK 10 X 40MM 1
21 HAE0307-01 PH8103021 A-FRAME STEEL BLANK 1
22 HAE0210 PH8103022 BRASS CYLINDER BLANK 8 X 17MM 1
23 HAE0128 PH8103023 BRASS HEXAGON BLANK 5.5 X 25MM 1
24 HAE0129 PH8103024 BRASS HEXAGON BLANK 5 X 17MM 1
25 HAE0313 PH8103025 BRASS PLATE BLANK 51 X 10 X 3MM 1
26 HAE0305 PH8103026 STEEL ROD BLANK 4 X 20MM 1
27 HAE0304 PH8103027 BRASS PLATE BLANK 23 X 10 X 3MM 2
28 HAE0303 PH8103028 STEEL ROD BLANK 4 X 36MM 2
30 HAE0312 PH8103030 ALUMINUM CYLINDER BLANK 92 X 17MM 1
32 HAE0307-02 PH8103032 BRASS CYLINDER BLANK 11 X 46MM 1
33 RB2-02 PH8103033 COOLING PISTON 22MM 1
34 RQ2.02-00 PH8103034 HEATING PISTON 63MM 1
35 HAE0315 PH8103035 ALUMINUM HOLLOW CYLINDER BLANK 25 X 13MM 1
