14
307–636
Technical Data
Category Data
Maximum pump fluid working pressure 950 psi (6.6 MPa, 66 bar)
Recommended air operating range 20 to 95 psi (150–660 kPa, 1.5–6.6 bar)
Pump ratio 10:1
Maximum recommended pump speed fo
continuous operation
60 cpm; (1.0 gpm [3.8 lpm]) delivery
Air consumption approx. 15 scfm (0.43 m 3 /min) at 1 gpm (3.8 lpm) flow rate at 95
psi (660 kPa, 6.6 bar) air pressure
Air inlet size 1/2 npt(f); use 1/2” ID air hose
Fluid filter 60 mesh (250 micron) screen
Wetted parts See separate component instruction manuals
Height 30 in (762 mm)
Width 15.5 in (394 mm)
Depth 14.75 in (375 mm)
Weight 52 lb (24 kg)
Manual Change Summary
This manual was revised to include the changes from PCN H, ECO V1305, and ECO V3726.
