G2891 Lathe Copy Attachment
-19-
Customer Service #: (570) 326-3806 • To Order Call: (800) 523-4777 • Fax #: (800) 438-5901
maChIne data
Sheet
GrIzzLy modeL G2891
Wood Lathe Copy attaChment
design type:
Drive .......................................................................................Manual, Cable-Operated
Wood Lathe Compatibility .......... 14" Swing Over Bed with Cast or Channel Bedways
Copy Pattern ........................................................Existing Spindle or Plywood Pattern
overall dimensions:
Length ...................................................................................................................52
3
⁄
8
"
Width .....................................................................................................................16
1
⁄
8
"
Depth .......................................................................................................................7
5
⁄
8
"
Shipping Weight ..................................................................................................68 lbs.
Net Weight...........................................................................................................60 lbs.
Box Size ..................................................................................... 55" L x 18" W x 10" h
Capacities:
Maximum Copy Length ............................................................................................36"
Maximum Total Depth of Cut ......................................................................................2"
Maximum Original Spindle Diameter .........................................................................3"
Maximum Recommended Cutting Depth per Pass ..................................................
1
⁄
16
"
height of Cutting Tool Above Bedway .....................................................................6
3
⁄
4
"
Construction:
Body ...............................................................................Extruded Aluminum and Steel
Duplicating head and Mounting Brackets .......................................................Cast Iron
Cutter .................................................................................................high Speed Steel
Specifications, while deemed accurate, are not guaranteed.
