-5-
Model g0453z/g0454z (Mfg. 1/09+)
The information contained herein is deemed accurate as of 10/17/2010 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
PAGE 1 OF 2
Model G0453Z
MACHINE DATA
SHEET
Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G0453Z 15" 3 HP 220V PLANER WITH SPIRAL
CUTTERHEAD
Product Dimensions:
Weight.............................................................................................................................................................. 655 lbs.
Length/Width/Height.................................................................................................................42 x 32-1/2 x 45-7/8 in.
Foot Print (Length/Width)....................................................................................................................... 22-1/2 x 22 in.
Shipping Dimensions:
Type........................................................................................................................................................... Wood Crate
Content............................................................................................................................................................ Machine
Weight.............................................................................................................................................................. 675 lbs.
Length/Width/Height............................................................................................................................. 31 x 30 x 47 in.
Electrical:
Minimum Circuit Size........................................................................................................................................ 20 amp
Switch........................................................................................................ Magnetic with Thermal Overload Protector
Switch Voltage...................................................................................................................................................... 220V
Cord Length............................................................................................................................................................ 5 ft.
Cord Gauge....................................................................................................................................................12 gauge
Plug Included............................................................................................................................................................No
Recommended Plug/Outlet Type...........................................................................................................................6-20
Motors:
Main
Type.................................................................................................................. TEFC Capacitor Start Induction
Horsepower.................................................................................................................................................3 HP
Voltage........................................................................................................................................................220V
Phase........................................................................................................................................................Single
Amps.............................................................................................................................................................15A
Speed.................................................................................................................................................3450 RPM
Cycle..........................................................................................................................................................60 Hz
Number Of Speeds........................................................................................................................................... 1
Power Transfer ..................................................................................................................... Triple V-Belt Drive
Bearings..........................................................................................................................Sealed and Lubricated
Main Specifications:
Operation Info
Max. Cut Width...........................................................................................................................................15 in.
Min. Stock Length........................................................................................................................................8 in.
Min. Stock Thickness.............................................................................................................................. 3/16 in.
Max. Stock Thickness.................................................................................................................................. 8 in.
No. Of Cuts Per Inch...............................................................................................................................56, 104
No. Of Cuts Per Minute............................................................................................................................20,000
Cutterhead Speed..............................................................................................................................5000 RPM
Planing Feed Rate............................................................................................................................16, 30 FPM
Max. Cut Depth Planing Full Width......................................................................................................... 3/32 in.
Max. Cut Depth Planing 6 Inch Wide Board..............................................................................................1/8 in.
