Models
4 312414D
Stain
Waterborne
High Wear
Adhesives Spatter Gun
Orifice
Size
in. (mm)
Conventional HVLP Compliant
Model Series
Max.
HVLP/Compliant
Air Pressure
psi (MPa, bar) Model Series
Max.
HVLP/Compliant
Air Pressure
psi (MPa, bar) Model Series
Max.
HVLP/Compliant
Air Pressure
psi (MPa, bar)
0.020 (0.5) 288958 A N/A 288960 A 22 (0.15, 1.5) 288962 A 29 (0.2, 2.0)
0.030 (0.8) 288959 A N/A 288961 A 22 (0.15, 1.5) 288963 A 29 (0.2, 2.0)
0.040 (1.0) 289109 A N/A 289110 A 22 (0.15, 1.5) 289111 A 29 (0.2, 2.0)
Orifice
Size
in. (mm)
Conventional HVLP Compliant
Model Series
Max.
HVLP/Compliant
Air Pressure
psi (MPa, bar) Model Series
Max.
HVLP/Compliant
Air Pressure
psi (MPa, bar) Model Series
Max.
HVLP/Compliant
Air Pressure
psi (MPa, bar)
0.030 (0.8) 288964 A N/A 288967 A 23 (0.16, 1.6) 288970 A 23 (0.16, 1.6)
0.042 (1.1) 288965 A N/A 288968 A 23 (0.16, 1.6) 288971 A 23 (0.16, 1.6)
0.055 (1.4) 288966 A N/A 288969 A 23 (0.16, 1.6) 288972 A 23 (0.16, 1.6)
Orifice
Size
in. (mm)
Conventional HVLP Compliant
Model Series
Max.
HVLP/Compliant
Air Pressure
psi (MPa, bar) Model Series
Max.
HVLP/Compliant
Air Pressure
psi (MPa, bar) Model Series
Max.
HVLP/Compliant
Air Pressure
psi (MPa, bar)
0.059 (1.5) 288973 A N/A 288976 A 20 (0.14, 1.4) 288979 A 29 (0.2, 2.0)
0.070 (1.8) 288974 A N/A 288977 A 20 (0.14, 1.4) 288980 A 29 (0.2, 2.0)
0.086 (2.2) 288975 A N/A 288978 A 20 (0.14, 1.4) 288981 A 29 (0.2, 2.0)
Orifice Size
in. (mm)
Conventional
Model Series
Max.
HVLP/Compliant
Air Pressure
psi (MPa, bar)
0.051 (1.3) 288982 A N/A
0.070 (1.8) 288983 A N/A
Orifice Size
in. (mm)
HVLP
Model Series
Max.
HVLP/Compliant
Air Pressure
psi (MPa, bar)
0.042 (1.1) 288985 A 30 (0.21, 2.1)
