GXV3601 IP Camera
Firmware 1.0.4.6 Page 16 of 36
Grandstream Networks, Inc. 09/2010
Items on GXV3601 Home Page
1 Motion Detection If the motion detection alarm is triggered, the indicator will flash
red . Click on the indicator to turn off the alarm.
2 Alarm Event If an alarm event is triggered, the indicator will flash red . Click
on the indicator to turn off the alarm.
3 Control Console PTZ Console controller. PTZ device needs to be connected.
4 ZOOM NOTE : GXV3601 does not support zoom
5 FOCUS Adjusts the focus of images.
6 Default
Click this option to reset the video brightness, contrast, and
saturation to their factory default configuration.
7 SPEED Adjusts the rotation speed of the console.
8 BRIGHTNESS Adjusts the image brightness.
9 CONTRAST Adjusts the image contrast.
10 SATURATION Adjusts the image saturation.
11
12
View Size
Play
Resize the image to fit into the window panel in the home
scream.
Plays/Stops the video.
13 Capture Captures the image displayed and saves it to C:\GS_Capture
(default directory).
14 Record Records the video and saves it to C:\GS_Record (default
directory).
15 Sound Off/On
Toggles the sound On or Off.
16 Talk Establishes two-way audio.
17 Playback
Replays the saved video.
18 Config Configures the Save Location for captured images and
recorded videos.
GXV3601 System Page
This page allows you to configure the system settings on GXV3601.
Current System Time
- displays the
current date and time (24h clock).
Set the System Time
Update via NTP Server
- the camera will obtain
the time from an NTP
server Specify the NTP
server's IP address or
