Section 6 — Exploded Views and Parts List
ATS “HS” Type Transfer Switch
200A Transfer Switch Assembly – Drawing No. 0E9801$-F
ITEM PART
NO. QTY.
DESCRIPTION
1
0D9618 1
TRANSFER SW-HSB 200A 2P 250V
2
0E3628
1
CIRCUIT BREAKER 0200A 2P 120/240V S QN
3 0E3664 1
BASE QN CIRCUIT BREAKER
4
0E3553 2
BUSBAR 200A HSB XFER SW
5
0E3375 4
LUG
SLDLSS 250-#6 AL/CU
6
0F1252
4
SCREW BHSC 1/4-20 X 3/8
7
036656 2
SCREW SHC 1/4-20 X 1 G8.8 NZ
8
022127
2
NUT HEX 1/4-20 STEEL
9 0E6523
1
GROUND BAR (5)4-14 AWG CONN
10
063617
1
RELAY PNL 12VDC DPDT 10A@240VA
11
0D2806
2
FUSEBLOCK 30A 600V 2POS W/SQ
12
073590A 4
FUSE 5A X BUSS
13
047822
1
BLOCK TERM 20A 7 X 6 X 1100V
14
0A1661
2
RIVET POP .156 X .675 AL
15
0C4449A 1
ASS’Y-NTRL BL150-200A
16
090388 2
SCREW HHTT M6-1.0 X 12 ZINC
17
0E1473 1
WELDMENT
TRANSFER SWITCH BOX
18
0E9989 1
COVER
INSIDE XFER SWITCH BOX
19 0E1477
1
COVER
TRANSFER SWITCH BOX
20
0F0668
1
DECALTRANSFER SWITCH
21
0E3070 1
SUBPLT XFER SW HSB
22
0E3477 REF
DECAL
SWITCH RATING
23 0E3484
1
DECAL WARN MANUAL OPER HANDLE
24
0E3485 1
DECAL
SERVICE DISCONNECT
25
067210A
1
DECAL GROUND LUG (NOT SHOWN)
26
0A9457 1
DECAL
NEUTRAL
27
0D3587 1
DECAL
FUSE REPLACEMENT
28
0A2595 1
DECAL
TERMINAL
STRIP
29 0E7109 1
DECAL
TEST SEQ.2P TS HS 3R
30 063378 8
HOLDER
CABLE
TIE
31 045764
8
SCREW HHTT M4-0.7 X 8 BP
32 049813
5
NUT HEX M6 X 1.0 G8 YEL CHR
33 074908 2
SCREW HHTT M5-0.8 X 10 BP
34 0C3992 2
SCREW HHTT M4-0.7 X 16 BP
35 026579 2
WASHER SHAKEPROOF EXT #8 STEEL
36 0E7213 2
SCREW THUMB 1/4-20 X 1/2 W/SHLD
37 022473 14
WASHER FLAT 1/4-M6 ZINC
38 022097 10
WASHER LOCK M6-1/4
39 0E9987 1
WIRE
HARNESS HSB (NOT SHOWN)
40
0E6193 1
BRACKET
ARM
EXTENDER
41
064526
2
SCREW HWHS #6-25 X 3/8
42 *
0E6155
1
ARM EXTENDER PIN
43 * 0E6032 2
90 DEGREE UP SPADE CONNECTOR
44 * 0E6033 2
90 DEGREE DN SPADE CONNECTOR
45 * 0E6034 2
STRAIGHT SPADE CONNECTOR
46
0E6303 1
WIRE
A
47
0E6303A 1
WIRE
B
48
0E6303B 1
WIRE
E1
49 0C8308 1
DECAL
TERMINAL
SHOCK HAZARD
50
081221
1
DECAL-UL
LIST HSB
51
0E9999 1
DECAL-SERVICE DISCONNECT SWITCH
52
0E9988 1
BRACKET
SERVICE SWITCH
53 0D3728 1
TOBBLE
SWITCH, SERVICE
54
095282 1
DECAL
LIVE-CIRCUIT
55
0F2712
1
DECAL
XFER
SWITCH DATA SE 200A
56
066849 5
SCREW HHTT M5-0.8 X 16
* SUPPLIED WITH TRANSFER SWITCH ITEM #1
