Page 15
13
I
TEM PART
NO. QTY.
DESCRIPTION
1
0C2237 1
TRANSFER SW-HSB 100A 2P 250V
2
0E7886H
1
CB 0100A 2P 240V S BQ2 LB
3 0E7890
1
BRKT CB MTG BACK
4
0E9906 1
BRACKET,
DISCONNECT SWITCH 100A
5
063378 8
HOLDER,
CABLE
TIE
6
0D3728 1
SWITCH TOG SPST 15A @ 125V
7
0E9999 1
DECAL
SERVICE DISCONNECT SWITCH
8
049813
4
NUT HEX M6 X 1.0 G8 YEL CHR
9 0E6523
1
GROUND BAR (5)4-14 AWG CONN
10 *** 063617
1
RELAY PNL 12VDC DPDT 10A@240VA
11 *** 0D2806
2
FUSEBLOCK 30A 600V 2POS W/SQ
12
073590A 4
FUSE 5A X BUSS
13 ***
047822
1
BLOCK TERM 20A 7 X 6 X 1100V
14
0A1661
2
RIVET POP .156 X .675 AL
15
0C4449 1
ASS’Y-NTRL BL 150-200A
16
090388 2
SCREW HHTT M6-1.0 X 12 ZINC
17
0E1473 1
WELDMENT
TRANSFER SWITCH BOX
18
0E9907 1
COVER
INSIDE XFER SWITCH BOX
19 0E1477
1
COVER
TRANSFER SWITCH BOX
20
0F0668
1
DECALTRANSFER SWITCH
21
0E3070 1
SUBPLT XFER SW HSB
22
0E9734 REF
DECAL
SWITCH RATING
23 0E3484
1
DECAL WARN MANUAL OPER HANDLE
24
0E3485 1
DECAL
SERVICE DISCONNECT
25
067210A
1
DECAL GROUND LUG (NOT SHOWN)
26
0A9457 1
DECAL
NEUTRAL
27
0D3587 1
DECAL
FUSE REPLACEMENT
28
0A2595 1
DECAL
TERMINAL
STRIP
29 0F0776
1
DECAL
TEST SEQ. 2P TS HS 3R
30 081221
1
DECAL-UL
LIST HSB
31 045764
6
SCREW HHTT M4-0.7 X 8 BP
32 074908 2
SCREW HHTT M5-0.8 X 10 BP
33 066849B 2
SCREW HHTT M5-0.8 X 8 BP
34 0C3992 2
SCREW HHTT M4-0.7 X 16 BP
35 026579 2
WASHER SHAKEPROOF EXT #8 STEEL
36 0E7213 2
SCREW THUMB 1/4-20 X 1/2 W/SHLD
37 022473 8
WASHER FLAT 1/4-M6 ZINC
38 022097 4
WASHER LOCK M6-1/4
39 0E9987 1
WIRE
HARNESS HSB (NOT SHOWN)
40
0E6193 1
BRACKET
ARM
EXTENDER
41
064526
2
SCREW HWHS #6-25 X 3/8 ZNC
42 **
0E6155
1
ARM EXTENDER PIN
43
036933 6
SCREW PPHM #10-32 X 3/8
44
077033 6
LUG
SLDLSS 1/0-#14X9/16 AL/CU
45
0C8308 1
DECAL
TERMINAL
SHOCK HAZARD
46
022152
6
WASHER LOCK #10
47
0912970085 1 WIRE
ASSY 2AWG 100A 2-P T/S N1A
48
0912970086 1 WIRE
ASSY 2AWG 100A 2-P T/S N2A
49
095282 1
DECAL
LIVE-CIRCUIT
50
0F2710
1
DECAL
XFER
SWITCH DATA SE 100A
51
066849 4
SCREW HHTT M5-0.8 X 16
52
0E6303
1
WIRE – A
53 0E6303A
1
WIRE – B
54
0E6303C
1
WIRE – E1
*** SUPPLIED WITH WIRE HARNESS ITEM #39
** SUPPLIED WITH TRANSFER SWITCH (ITEM #1)
Section 6 — Exploded Views and Parts List
ATS “HS” Type Transfer Switch
100A Transfer Switch Assembly – Drawing No. 0F0466$-D
