Grandstream Networks GSM gateway - Manual (Page 15)

Februaray-2006 Page 15 / 42
MasterVoIP
VoIP to GSM Gateway
3.2 Configuration Guide
3.2.1 Configuring VOIP Client with a Web Browser
VoIP Client ATA has an embedded Web server that will respond to HTTP GET/POST requests.
VoIP Client ATA is enabled with embedded HTML pages, which allow a user to configure the IP phone,
through a Web browser, such as Microsoft’s IE and AOL’s Netscape.
3.2.1.1 Access the Web Configuration Menu
First, get the IP address of the VOIP Client through section 2.1 with menu option 02. Then access the
VOIP Client’s Web Configuration Menu using the following URI: http://Phone-IP-Address where the Phone-IP-
Address is the IP address of the phone.
3.2.1.2 End User Configuration
Once this request is entered and sent from a Web browser, the IP phone will respond with the following login screen
:
The password is case sensitive with a maximum length of 25 characters. The factory default password
for End User is “admin”. After the correct password is entered in the login screen, the embedded Web server inside the IP
phone will respond with the following Basic Settings configuration page, which is explained in details below.
