SPINDLE ASSEMBLY
Spindle Assembly - 61
ITEM PART NO QTY DESCRIPTION
1 200262 1 Spindle Assembly - Includes items 2, 3, 4, 5, 6, 14
2 200046 2 Ball Bearing
3 200042 1 Housing
4 200044 1 Spacer - 1.000 x 1.250 x 2.772
5 200262 1 Shaft, Spindle
6 200045 6 Bolt, 3/8-16 x 1.25 Rib
7 D13055 3 Nut, Pulley (Special)
8 N/A 3 Pulley, Cutter Housing - See Mower Assembly Pages
9 D13024 3 Spacer, Pulley
10 967347 3 Bolt, Blade - 5/8-11 x 2.25 Grade 8
11 960502 18 Nut, 3/8-16 Std Hex Gr5
12 D18055 9 Spacer, Blade Bolt
13 GDU10231 3 18.0" Blade, 52" Deck
14 200047 1 Zerk, Grease S/O
