CONSOLE AND BATTERY ASSEMBLY
Console and Battery Assembly - 53
iTEM
PART NO
QTY
DESCRIPTION
1
D18079
1
GRIP, PVC .250 X 1.00 X 3.63
2
D28159
1
STRIP, BATTERY INSULATOR
3
TCU16323
1
LABEL. PARK BRAKE DIRECTION
4
03H1832
2
BOLT, 5/16-18 X 6.00 CRG 2 Y
5
111886
1
P-CLIP, .500 INSULATED
6
121080
3
PIN, HAR .091 X 1.63 5/16-1/2 Y
7
180640
1
SOLENOID, 12 V STARTER
8
180842
1
CABLE, 12” STARTER
9
181148
1
CABLE, BATTERY STARTER - 48”
10
191832
1
BATTERY, 12V-U1-CCA270MIN
11
N/A
1
ASSEMBLY, CONTROL PANEL
12
200606
1
PAD, THIGH
13
200787
1
TRAY, BATTERY
14
200614
1
LEVER, BRAKE
15
200615
1
LINK. BRAKE Y
16
200671
1
BUSHING, BRAKE PIVOT Y
17
200690
1
WLDT, THIGH PAD BRACKET
18
200692
2
BUSHING, .364X.540X1.250 Y
19
200705
1
SWITCH, NO-NO-NC GREY PLUNGER
20
181148
1
CABLE, BATTERY STARTER - 51”
21
963020
4
BOLT, 3/8-16 X 1.00 CRG 5 Y
22
960000
2
BOLT, 1/4-20 X .500 HEX 5 Y
23
960001
9
BOLT, 1/4-20 X .750 HEX 5 Y
24
960047
1
BOLT, 3/8-16 X 1.25 HEX 5 Y
25
960600
6
WASHER, .250 MED SPRG LOCK Y
26
963001
2
BOLT, 1/4-20 X .625 WSH Y
27
964040
2
LOCKNUT, 1/4-20 WHIZ Y
28
964048
3
LOCKNUT, 1/4-20 NYLOC Y
29
967115
6
LOCKNUT, 5/16-18 NYLOC Y
30
967185
2
BOLT, 5/16-18 X 2.00 CRG 5 Y
31
968087
8
LOCKNUT, 3/8-16 NYLOC Y
32
200745
1
WELDMENT, CONSOLE
