Model t10446 heavy-duty hammer drill -13 -
parts list
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PT10446001 CLIP 8MM 60 PT10446060 GEARBOX BOTTOM COVER
2 PORS038 O-RING 37.5 X 2.0 S38 61 P627-OPEN BALL BEARING 627 OPEN
3 PT10446003 GREASE CUP COVER 62 PT10446062 RETAINER NUT
4 PT10446004 GEARBOX ASSEMBLY 63 PT10446063 LOCK WASHER
5 PT10446005 BALL BEARING 906 OPEN 64 PT10446064 FLAT WASHER
6 PT10446006 NEEDLE BEARING HK0810 65 PT10446065 THRUST WASHER
7 PT10446007 CONNECTION ROD 66 PT10446066 GEAR
8 PT10446008 DRIVE PISTON 67 PT10446067 SPACER
9 PT10446009 PISTON KEY 68 P6002-OPEN BALL BEARING 6002 OPEN
10 PT10446010 O-RING 19 X 3.2 69 PT10446069 SPACER
11 PT10446011 IMPACT PISTON 70 PT10446070 GEAR SHAFT
12 PT10446012 GEAR SLEEVE 71 PT10446071 DEEP-GROOVE BALL BEARING 10088
13 PT10446013 CLUTCH HOUSING 72 PT10446072 SHAFT RING 12MM
14 PORS055 O-RING 54.5 X 2 S55 73 PT10446073 DRIVE GEAR
15 PT10446015 RUBBER RING 74 PT10446074 SPACER
16 PT10446016 BALL BEARING 907 ZZ 75 PCAP23M CAP SCREW M4-.7 X 12
17 PT10446017 SPACER 76 PLW02M LOCK WASHER 4MM
18 PT10446018 CYLINDER SEAL 77 PT10446077 BEARING COVER
19 PT10446019 O-RING 19.2 X 2.95 78 P6202-OPEN BALL BEARING 6202 OPEN
20 PT10446020 CYLINDER 79 PT10446079 SHAFT KEY
21 PK96M KEY 3 X 3 X 20 80 PT10446080 ECCENTRIC DRIVE SHAFT
22 PT10446022 STEEL BALL 7MM 938 81 PHTEK18M TAP SCREW M3.5 X 10
23 PT10446023 OIL SEAL 82 PT10446082 LEFT HANDLE
24 PT10446024 OUTER CLIP 35MM 84 PT10446084 SWITCH COVER
25 PT10446025 IMPACT ROD 85 PT10446085 ON/OFF SWITCH
26 PT10446026 O-RING 11 X 1.9 86 PT10446086 RIGHT HANDLE
27 PT10446027 TRANSIT SLEEVE 87 PHTEK17M TAP SCREW M5 X 20
28 PT10446028 STEEL BALL 7.14MM 88 PT10446088 HANDLE GRIP
29 PT10446029 O-RING 19.8 X 2.1 89 PHTEK18M TAP SCREW M3.5 X 10
30 PT10446030 COMPRESSION SPRING 92 PT10446092 STRAIN RELIEF
31 PT10446031 HEAD HOUSING 93 PT10446093 POWER CORD
39 PT10446039 SLIDING SLEEVE ASSEMBLY 94 PT10446094 AUXILIARY HANDLE
40 PT10446040 SPACER 95 PT10446095 HANDLE BRACKET
41 PT10446041 BLOCKING RING 96 PT10446096 DEPTH STOP BRACKET
42 PT10446042 NOSE PIECE 97 PT10446097 DEPTH STOP ROD
43 PCAP24M CAP SCREW M5-.8 X 16 98 PT10446098 AUXILIARY HANDLE HARNESS
44 PLW01M LOCK WASHER 5MM 99 PT10446099 HANDLE SCREW
45 PW02M FLAT WASHER 5MM 101 PT10446101 COMPRESSION SPRING
48 PT10446048 ROTOR HOUSING 102 PT10446102 CLUTCH
49 PHTEK18M TAP SCREW M3.5 X 10 103 PT10446103 INNER CLIP 47MM
50 PT10446050 CARBON BRUSH BRACKET 104 PT10446104 SPACER
51 PT10446051 CARBON BRUSH SET 2PC 105 PT10446105 O-RING 28 X 1.5
52 PT10446052 CARBON BRUSH CAP 106 PT10446106 DUST CUP
53 PCAP24M CAP SCREW M5-.8 X 16 107 PT10446107 RIGHT TOOL ID LABEL
54 PT10446054 STATOR ASSEMBLY 108 PT10446108 LEFT TOOL ID LABEL
55 PT10446055 STATOR COVER 109 PT10446109 GRIZZLY LOGO LABEL
56 PHTEK18M TAP SCREW M3.5 X 10 110 PT10446110 READ MANUAL LABEL
57 P608ZZ BALL BEARING 608 ZZ 111 PT10446111 EYE-HEARING HAZARD LABEL
58 PT10446058 ROTOR ASSEMBLY 112 PT10446112 CARRYING CASE
59 P6001ZZ BALL BEARING 6001 ZZ
