Grizzly Industrial Die H6193 User Manual

Model h6193, Industrial die grinder, Instruction sheet

background image

Introduction

No load speed is 22,000 RPM and collet size is

1

4

".

Requires a maximum of 90 PSI with a minimum of
4 CFM compressor capacity. Air inlet is

1

4

" and air

exhaust is in the front. Weighs 1.2 lbs.

Inventory

A. Die Grinder ................................................. 1

B. Wrenches ................................................... 2

Operation

Insert your

1

4

" shank tool into the collet. Using the

two wrenches, secure tool by tightening the collet
against the spindle.

MODEL H6193

1

4

" INDUSTRIAL

DIE GRINDER

INSTRUCTION SHEET

Figure 1.

Model H6193.

CoPyRIGHt © FebRUARy, 2006 by GRIzzly INDUStRIAl, INC. RevISeD SePteMbeR, 2009 (bl)

WARNING: NO pORTION OF THIS MANUAL MAy BE REpRODUCED IN ANy SHApE

OR FORM WITHOUT THE WRITTEN AppROvAL OF GRIzzLy INDUSTRIAL, INC.

#PC8031 PRINteD IN tAIWAN

Figure 2.

lubricating directly into air fitting.

If you need help with your new pneumatic tool, call
our Tech Support at: (570) 546-9663.

Die Grinder MUSt have 3-4 drops of oil directly
dropped into the air fitting before each use as
shown in

Figure 2.

INJURy HAzARD!

Always disconnect tool from

air to prevent unexpected

operation during service!

EyE/EAR INJURy HAzARD!

Wear safety glasses and

hearing protection during

use of this tool!

RESpIRATORy HAzARD!

Grinding produces fine

dust. Wear the appropriate

protection during use!

EXpLOSION HAzARD!

Never exceed 90 pSI! Always

use accessories with correct

speed rating.
