Headstock parts list, O&&m'+avi]zl$ Page 2
Page 2
<..,'O&&m'+AVi]Zl$ "*," Headstock Parts List REF PART # DESCRIPTION REF PART # DESCRIPTION 1 P9972Z0001 HEADSTOCK NAMEPLATE 28 PW04M FLAT WASHER 10MM 2 PS17M PHLP HD SCR M4-.7 X 6 29 PSB50M CAP SCREW M5-.8 X 10 5 PSB06M CAP SCREW M6-1 X 25 30 PW23M FLAT WASHER 30MM 6 PW03M FLAT WASHER 6MM 31 P9972Z0031 IDLER SHAFT 7 P9972Z0007 COMPRESSION SPRING .8 X 8 X 20 32 P9972Z0032 TIMING BELT 8 P9972Z0008 THREADED BLOCK 33 P6001-2R2 BALL BEARING 6001-2RS 10 PSB06M CAP SCREW M6-1 X 25 34 P9972Z0034 IDLER PULLEY 11 P9972Z0011 SPINDLE 35 PR49M INT RETAINING RING 12MM 12 PK123M KEY 10 X 10 X 55 36 P9972Z0036 SPECIAL WASHER 13 P9972Z0013 SPACER 37 P9972Z0037 MOTOR PULLEY 14 P32009 TAPER ROLLER BEARING 32009 38 PK11M KEY 6 X 6 X 40 15 P9972Z0015 HEADSTOCK CASTING 39 PR45M INT RETAINING RING 10MM 16 PSB14M CAP SCREW M8-1.25 X 20 40 P9972Z0040 DOUBLE ENDED THREADED STUD 17 P32009 TAPER ROLLER BEARING 32009 41 P9972Z0041 PIVOT BRACKET 17-1 P9972Z0017-1 BEARING CAP 42 PW04M FLAT WASHER 10MM 18 PS26M PHLP HD SCR M6-1 X 20 43 PN02M HEX NUT M10-1.5 19 P9972Z0019 SPACER 44 P9972Z0044 TENSIONING SHAFT 20 P9972Z0020 GEAR 45T 45 P6001-2R2 BALL BEARING 6001-2RS 21 PVM29 V-BELT M-29 3L290 46 P9972Z0046 IDLER ROLLER 22 P9972Z0022 SPINDLE PULLEY 47 PR20M INT RETAINING RING 28MM 23 PVM32 V-BELT M-32 3L320 48 PR03M EXT RETAINING RING 12MM 24 P9972Z0024 SPANNER NUT M30-3.5 49 P9972Z0049 CHANGE GEAR COVER 25 P9972Z0025 BRACKET PLATE 51 PN06M HEX NUT M5-.8 26 PLW06M LOCK WASHER 10MM 52 P9972Z0052 OUTBOUND SPINDLE COVER 27 PN02M HEX NUT M10-1.5 53 PS08M PHLP HD SCR M5-.8 X 12
