Sanding motor system parts list, Eavczg$hvcyzg – Grizzly G0677 User Manual
Page 3
<%+,,')EaVcZg$HVcYZg
",("
Sanding Motor System Parts List
REF
PART #
DESCRIPTION
REF
PART #
DESCRIPTION
101
P06771101
MACHINE FRAME
205
PB84
HEX BOLT 3/8-16 X 3-1/2
102
P06771102
MOTOR BASE
206
PN08
HEX NUT 3/8-16
103
PH29331103
MOTOR BASE HINGE
208
PH29331208
IDLER WHEEL SHAFT
104
PN41
HEX NUT 1/2-12
209
P6305
BALL BEARING 6305ZZ
105
PH29331105
MOTOR BASE ADJ. ROD
210
P06771210
IDLER PULLEY
106
PLW07
LOCK WASHER 1/2
211
P6206
BALL BEARING 6206-ZZ
107
PB41
HEX BOLT 1/2-12 X 1-1/2
212
PR11M
EXT RETAINING RING 25MM
108
PW01
FLAT WASHER 1/2
213
P06771213
V-BELT B52 5L540 QTY 2
109
P06771109
MOTOR 15HP 220/440V 3PH
301
PH29331301
BRAKE CALIPER
109-1 H29331109-1
MOTOR FAN
301-1 PH29331301-1
BRAKE CALIPER FRONT GUARD
109-2 H29331109-2
MOTOR FAN COVER
302
PH29331302
BRAKE LINING SET
110
P06771110
MOTOR PULLEY
303
PH29331303
BRAKE ARBOR
111
PSB11
CAP SCREW 5/16-18 X 1-1/4
304
PH29331304
BRAKE COMPRESSION SPRING
112
PLW01
LOCK WASHER 5/16
305
PH29331305
BRAKE INSIDE PIECE
113
PH29331113
KEY 12 X 8 X 105
306
PFH04
FLAT HD SCR 1/4-20 X 5/8
114
PB03
HEX BOLT 5/16-18 X 1
307
PH29331307
BRAKE PIN
115
PLW01
LOCK WASHER 5/16
308
PSB31
CAP SCREW 10-24 X 5/8
116
PH29331116
BRAKE ROTOR
310
PLW04
LOCK WASHER 3/8
117
P06771117
V-BELT B-74 5L770 QTY 2
311
PN08
HEX NUT 3/8-16
118
PH2933118
PULLEY BUSHING
312
PSB04
CAP SCREW 1/4-20 X 1/2
119
P06771119
V-BELT B-55 5L580 QTY 2
313
PH29331313
BRAKE GASKET
121
PH29331121
BRAKE BRACKET
320
P06771320
FOOT PEDAL HOOK
122
PW02
FLAT WASHER 3/8
321
PSB107
CAP SCREW 3/8-16 X 2
123
PB21
HEX BOLT 3/8-16 X 3/4
322
PN08
HEX NUT 3/8-16
124
PH29331124
FLAT HEAD NUT
323
PLW04
LOCK WASHER 3/8
125
PSB05
CAP SCREW 1/4-20 X 3/4
324
PW07
FLAT WASHER 5/16
126
PH29331126
TABLE LIMIT SWITCH
325
PLW01
LOCK WASHER 5/16
127
PH29331127
TABLE LIMIT SWITCH PLATE
326
PB32
HEX BOLT 5/16-18 X 5/8
128
PB02
HEX BOLT 1/4-20 X 5/8
327
P06771327
FOOT PEDAL SUPPORTER
129
PW06
FLAT WASHER 1/4
328
P06771328
FOOT PEDAL
132
PFH30M
FLAT HD SCR M5-.8 X 8
330
P06771330
SPECIAL SCREW
133
PLW02
LOCK WASHER 1/4
331
PLW01
LOCK WASHER 5/16
201
P06771201
IDLER WHEEL ADJ. BRACKET
332
PB09
HEX BOLT 5/16-18 X 1/2
202
PLW10
LOCK WASHER 3/4
337
P06771337
WING NUT 1/2
203
PN03
HEX NUT 3/4-16
342
P06771342
WIRING COVER
204
PW13
FLAT WASHER 3/4
