tracer2000 Network DVR Hardware User’s Manual

Version 3.1

Page 11 of 31

1.6

COM2 Mode Select (JP3)

Mode

JP3

RS232 3-5,

4-6,

9-11, 10-12, 17-18

RS422

1-3, 2-4, 7-9, 8-10, 15-16

RS485

1-3, 2-4, 7-9, 8-10, 13-14

1.7

CPU FSB Select (JP4)

Function

JP4

Auto by CPU

1-3, 2-4

66MHz 3-5,

4-6

1.8

FAN Control (FAN1, 2)

Function

FAN1, 2

Sense 3

+12V 2

PWM Control

1.9

HDD Connector (IDE1, 2)

Pin

No. Signal Pin

No. Signal

1 -RST 2 GND
3 D7 4 D8
5 D6 6 D9
7 D5 8

D10

9 D4 10

D11

11 D3 12

D12

13 D2 14

D13

15 D1 16

D14

17 D0 18

D15

19 GND 20 N.C.
21 REQ 22 GND
23 IOW 24 GND
25 IOR 26 GND
27 IORDY 28 GND
29 DACK 30 GND
31 IRQ 32 N.C.
33 A1 34

PDIAG

35 A0 36 A2
37 CS0 38 CS1
39 -ACT 40 GND
